Processing Technology
HOME>Technology
About the processing technology
Grind Treatment
We can process products with sub micron accuracy
◆Centerless Grinding
<Process accuracy>
・ outside … 0.0002mm
・ surface roghness … 0.0002mm
・ circularity … 0.0001mm

◆Surface grinding
<Process accuracy>
・ squareness … 0.001mm
・ surface roghness … RY 1.0 μ

◆Round grinding
<Process accuracy>
・ surface roghness … RY 0.3 μ

◆Super finish grinding
<Process accuracy>
・ surface roghness … RY 0.2 μ

◆side milling
<Process accuracy>
・ Dcut
・ Lcut
・ Hcut

Lathe Treatment
We can process products with micron accuracy.
◆Numerically controlled lathe
・ Process diameter … φ1.0〜φ20.00
・ Process length … L=2.0〜350.00

◆Cam shaft(automatic lathe)
・ Process diameter … φ1.5〜φ10.00
・ Process length … L=5.0〜50.00

◆ESCO matic
・ Process diameter … φ0.60〜φ4.0
・ Process length … L=1.0〜50.0

Knurl Treatment
We have various shapes
◆Flat mesh knurling
※please specify interval and

◆Ayame knurling
※please specify interval and

◆Screw
※please specify interval and

Heat Treatment
We can make a proposal for best condition to much all of use.
◆Bright Heat treatment Furnance
・We set process time for hardness and toughness

◆Vacum heat-Treatment Furnance
・We set process time for hardness and toughness

◆Subzero disposal
・We process for high hardness and stabilize the organization.

◆Nithiding
・depth of hardening is min 1mm.

◆Induction hardening
・We put products into induotion hardening and heat the surface.

◆Carburizing
・Hardening in the carburing materials.

Surface Treatment
We can propose the process methods wich can adaptable for using environments.
◆Passivation
・For the purpose of rust resistance.

◆Barell finish
・Surface roghness finish treatment.
・Rust resist treatment.

◆Electroless nickel plating

◆Aluminaless and Silliconless
・We take away the alumina and sillicon which are harmful when we use spinde motor and HDD.

◆Range designation surface roughness treatment
・We can manage the surface roughness

Minutureness production
We can process products with high accurate lightweight.
our top level tecnique laboratory have various kind of machinery and materals. which can only see in here.
・ Process diameter … φ0.4 ±0.001mm
・ Process length … L=1.0mm
・ circularity … 0.001mm
・ surface roghness … RY 0.3 μ

Other production
We can process with various kind of process
◆PIPE(seamless type・non seamless type)
・ materials … SUS303
SUS304
SUS316
SUS305

◆Press
・EGCE(material)

◆Header
・ materials … SWCH
XM7

◆Assenbly
・We can make proposal for cost down to match with BSBM.

Material
We have general materials and special materials
◆Carbon steels for machine structual use
・S−C

◆alloy steels
・SCM

◆Carbon steel tool
・SK
・SKS
・SKD

◆High speed tool steels
・SKH51〜57

◆stainless steels


・ martensite … SUS420J2
SUS420F2
SUS420F
SUS416
・ austenite … SUS303
SUS304
SUS316
・ ferrite … SUS430

◆Spring steels
・SW

◆Bearing steels
・SUJ1
・SUJ2

◆We have other special materials and high hardness.

Drill
We process with multipul process
◆process products
・ Process diameter … φ3mm〜φ30mm
・ Process length … 10mm〜450mm
・ Material … SKH51〜57
